Entrances

Our entrances

We, at Global Tardif, are experts in the conception, design, engineering and manufacturing of standard or custom architectural quality elevator entrances. For many years, we have recognized the importance of quality, excellence and performance down to the smallest details.

Our skilled, experienced and specialized personnel ensure you of our commitment to quality as well as performance with our manufacturing lead time.

Our entrances are manufactured using highly accurate laser and CNC machining operations. These new technologies ensure you a top quality product at the best economical cost.

To ensure easy field assembly and that it meets our quality standards, our entrances are test-assembled prior to leaving the factory.

Jamb profiles (PDF) Brochure

Product range

Single-speed sliding doors

Elevation & plan view (PDF)

• Econo (integral type) - with hangers, tracks & closers
We offer 36” (915 mm) wide by 84” (2134 mm) or 96” (2438 mm) high
and 42” (1067 mm) wide by 84” (2134 mm) or 96” (2438 mm) high.

• Conventional (none integral) - without hangers, tracks & closers (sold separately)
Any size from 22” (559 mm) up to 48” (1219 mm) by 120” (3048 mm) high.

Center opening doors

Elevation & plan view (PDF)

• Econo (integral type) - with hangers, tracks & closers
We offer 36” (915 mm) wide by 84” (2134 mm) or 96” (2438 mm) high
and 42” (1067 mm) wide by 84” (2134 mm) or 96” (2438 mm) high and 48” (1219 mm)
wide by 84” (2134 mm) or 96” (2438 mm) high.

• Conventional (none integral) - without hangers, tracks & closers (sold separately)
Any size from 30” (762 mm) up to 96 ” (2438 mm) by 120” (3048 mm) high.

Two-speed sliding doors

Elevation & plan view (PDF)

• Econo (integral type) - with hangers, tracks & closers
We offer 36” (915 mm) wide by 84” (2134 mm) or 96” (2438 mm) high
and 42” (1067 mm) wide by 84” (2134 mm) or 96” (2438 mm) high and
48” (1219 mm) wide by 84” (2134 mm) or 96” (2438 mm) high.

• Conventional (none integral) - without hangers, tracks & closers (sold separately)
We offer 36” (915 mm) wide by 84” (2134 mm) or 96” (2438 mm) high and 42” (1067 mm)
wide by 84” (2134 mm) or 96” (2438 mm) high and 48” (1219 mm) wide by 84” (2134 mm)
or 96” (2438 mm) high. Any size from 30” (762 mm) up to 96” (2438 mm) by 120” (3048 mm) high.

Two-speed center opening doors

Elevation & plan view (PDF)

• Conventional (none integral) - without hangers, tracks & closers (sold separately)
Any size from 33” (838 mm) up to 110” (2794 mm) by 120” (3048 mm) high.

Three-speed sliding doors

Elevation & plan view (PDF)

• Conventional (none integral) - without hangers, tracks & closers (sold separately)
Any size from 30” (762 mm) up to 110” (2794 mm) by 120” (3048 mm) high.
